Specifications
Product-Family Characteristics:
IP Rating, Static
IP65
Temperature Min
-25 °C / -13 °F
Temperature Max
65 °C / 149 °F
Anti-Rotation
yes
End Play, Max
1,0 mm / 0,039 in
Material
Stainless Steel, Aluminum, Zinc
Certifications
CE, UL, CSA
Restraining Torque
0 Nm
Special Connector
Flying Leads
Product Characteristics:
.
Feedback
Anti-coast brake and manual override
Nominal Stroke
600 mm
Front Adapter Option
Forked cross hole for 12 mm pin
Rear Adapter Option
Cross hole for 10 mm pin
Rear / Front Adapter Hole Position
Both adapters at 0° (standard position)
Weight
9.1 kg
Screw Type
Ball Screw Drive
Voltage
400 Vac
Dimension
Product Characteristics:
Nominal Stroke [S]
600 mm
Dimension [A]
873.4 mm
Performance
Product Characteristics:
Load, Static, Max
18.000 N
Load, Dynamic
2.250 N (229,5 kg / 506 lbf)
Duty Cyle
25%
Current Draw @ no load/max. Load
0,38 / 0,50 [A]
Salt Spray Resistance
96 hrs
Max. Speed
15 mm/s
Min. Speed
12 mm/s
